pH Electrode With Transmitter

pH Electrode With Transmitter

In many of the Pharma and beverages industries, DM or, WFI water is used where pH has to be monitored and output also would be required for remote Indication or, Control. In Effluent and Sewage treatment also pH has to be maintained after its processing.

We provide pH Electrode with panel mounted Digital pH Indicator with 4 to 20 mA output.

Details of Electrode :

Type of Electrode : Glass Tube type Electrode
Process Connections : 3/8” BSP (M)
Electrode Holder : PVC, PTFE or, SS
Electrode Holder Mounting : ¾” BSP (M)
Range : 0 to 14 pH
Resolution : 0.1
Max. Temperature : Electrode with PVC top cover up to 60 degree C
Electrode with PTFE top cover up to 100 degree C
Electrode with SS top cover up to 120 degree C
Max. Pressure : 6 bar
Electrical connection : Five meters cable with BNC connector
Approx. Length of the assembly : 120 mm

Details of Digital Indicating Transmitter :
Mounting : Panel mounted
Power Supply : 230 V AC
Display : 4 digit, 7 segment LED display
Dimensions : 96 X 96 X 110 mm
Output : Temperature compensated 4 to 20 mA and 1 no. 5 A, 230 V AC
